Led Poster Screen

Aluminum profile box design
USB, WIFI controller system
Light weight and super thin
Availability:
Quantity:

Same body for different pixel pitch P1.8, p2, P2.5, P3

Led module magnets installation, full front maintenance

No need extra truss for installation, saving installation cost

led poster screen1

FEATURES AND ADVANTAGE:


1. Ultra-thin and light-weight body——thickness is 40 mm and weighing less than 40 kg, making installation easy and fast .

3. HD visual experience——1.8mm,2mm,2.5 mm and 3 mm pixel pitch, high refresh rate (2000Hz) and brightness (1200 nits) provide users with perfect display effect.

4. Various work modes——besides single display work mode, multiple led display screen can be combined together creatively to bring a variety of display effect and improve the advertising efficiency.

5. Elegant appearance——aluminum- alloy frame, fully enclosed frosted rear cover, acrylic glass surface,I t is a mirror led display and customized border color present enchanting and eye-catching appearance.

6. Multiple communication modes——communication via USB, WIFI,4G, network cable and HDMI increase service efficiency.



1.Two installation for choosing

-Stand with bracket

-Stand with base

led poster screen 2

2. Support diversified control

- Wifi/Phone app

- Computer/PC

- USB-Disk

-3G/4G(remotely control)

Led poster display controller port

3. Widely application

Widely use on Airport, station, catering industry, entertainment industry, medical institution, golf course, supermarket, exhibition, stadium and gymnasium, financial industry, organ and enterprise, building adverting and billboard advertising, subway, hotel, rail way station, bus station, lift, bank, commercial center, wedding photograph, large exhibition, mobile show, chain-store and etc.

led poster screen-application2

led poster screen-application1

4. Various work modes

Besides single display work mode, multiple led display screen can be combined together

Led poster screen 3

Technology parameter:

LED poster screen



Item

P1.86

P2

P2

P2.5

P3

Pixel Pitch(mm)

1.86

2.0

2.0

2.5

3

LED Encapsulation

SMD1515

SMD2121

SMD2121

SMD2121

SMD2121

Module Resolution(pixels)

172x86

160x80

128x64

128x64

64x64

Module Size<WxH>(mm)

320x160

320x160

256x128

320x160

192x192

Panel Resolution(pixels)

344x1032

320x960

256x960

256x768

192x640

Panel Size<WxHxD>(mm)

640x1920

512x1920

512x1920

640x1920

576x1920

Physical Density (Pixels/m2)

288906

250000

250000

160000

111111

Optimum Viewing Angle

H:160° V:140°

H:160° V:140°

H:160° V:140°

H:160° V:140°

H:160° V:140°

Option Distance(m)

>2

>2

>2

>3

>4

Input Voltage

110-220VAC±10%

110-220VAC±10%

110-220VAC±10%

110-220VAC±10%

110-220VAC±10%

Max. Power Consumption(w/m2)

850

800

800

700

650

AVE. Power Con sum ption (w/m2)

500

450

450

300

350

Brightness(cd/m2)

700

900

900

1000

1000

Refresh Frequency (Hz)

>1920-3840

>1920-3840

>1920-3840

>1920-3840

>1920-3840

Frame Frequency(Hz)

60

60

60

60

60

Grayscale (bit)

16

16

16

16

16

Operating Temperature/Humidity(°C/RH)

-20°Cto +50°C/ 20% to 90%

-20°Cto +50°C/ 20% to 90%

-20°Cto +50°C/ 20% to 90%

-20°Cto +50°C/ 20% to 90%

-20°Cto +50°C/ 20% to 90%
